Basic

• Resolution
  5120 × 3840

• Max. Frame rate
  15 fps

• Sensor Type
  1"，CMOS

• Shutter Mode
  Global

• Pixel Size
  2.5 μm × 2.5 μm

• Lens Mount
  C-MOUNT

• Trigger Mode
  Software trigger/External trigger/Free run modes

• Software
  EasyID

• Certifications
  CE，KC

• Function
  lD: Code 39，Code 93，Code 128，CodaBar，EAN8，EAN13，UPCA，UPCE，ITF25，2of5（Industrial 2of5），standard25，GS1-128 etc. and 2D: QR/DM/MQR/GS1 DM/GS1 QR; Quality Evaluation: 1S0/IEC 29158(AIM-DPM), 1S0/IEC 15415, 1S0/IEC 15416

Performance

• Max. Read Speed
  90 codes/s

Port

• Connector
  2 Industrial connectors support GigE and GPIO

• Network Port
  Code-A,GigE

• GPIO Interface
  12Pins GPIO，RS232, 2 Opto-isolated inputs and 3 Opto-isolated outputs

• Communication Mode
  RS232, Ethernet

• Communication protocol
  SDK，TCP Client，FTP，TCP Server，RS232，Profinet、Modbus、EtherNet/IP、MCUdp、MCTcp、FinsUDP、FinsTCP、MELSEC

• LED Indicator
  Power,Ethernet,Trigger

Power

• Power Supply
  24VDC, 1A input, suitable for industrial environment

• Power Consumption
  <8.0W@DC24V (light not included)

Structure

• Product Dimensions
  117 mm × 69 mm × 43 mm(lens mount & connector not included)

• Net Weight
  ＜550 g

• Protection
  IP67 (with lens cover)

• Casing Material
  Aluminum alloy

Environment

• Operating Temperature
  -20℃～+50℃

• Operating Humidity
  20%～95%, no condensation

• Storage Temperature
  -30℃～+70℃
