Basic

• Resolution
  2368 × 1792

• Max. Frame rate
  45 fps

• Shutter Mode
  Global

• Mono/Color
  Mono

• Lens Mount
  M12, auto focus

• Trigger Mode
  Software trigger/External trigger/Free run modes

• Certifications
  CE，KC

• Function
  lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR etc.; Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）

Performance

• Focal Length
  8mm

• Working Distance
  80-1500mm

• Field of View
  196 × 148 mm@WD200mm

• Max. Read Speed
  90 codes/s

• Max. Operating Speed
  3m/s

• Min. Resolution
  1D code 0.04 mm/ 2D code 0.09 mm

• Light Source Type
  White

Port

• Connector
  2 Industrial connectors support GigE and GPIO

• Network Port
  GigE

• GPIO Interface
  RS232, 2 Opto-isolated inputs and 3 Opto-isolated outputs

• Communication Mode
  RS232, Ethernet

• Communication protocol
  SDK，TCP Client，TCP Server，FTP，RS232，Profinet、Modbus、EtherNet/IP、MC(SLMP)、FINS/UDP、FINS/TCP

• LED Indicator
  Power,Ethernet,Status,Result

Power

• Power Supply
  9~26VDC, 2A input, suitable for industrial environment

• Power Consumption
  <18 W(light included)

Structure

• Product Dimensions
  82mmx55mmx53mm(not including connector)

• Net Weight
  <350 g

• Protection
  IP65

• Casing Material
  Aluminum alloy + Front cover

Environment

• Operating Temperature
  -20℃～+50℃

• Operating Humidity
  20%～95%(no condensation)

• Storage Temperature
  -30℃～+70℃
