Basic

• Resolution
  640 × 512

• Max. Frame rate
  60 fps

• Shutter Mode
  Global

• Mono/Color
  Mono

• Lens Mount
  M8

• Trigger Mode
  Support multiple trigger modes such as software trigger/external trigger/free run;

• Software
  EasyID

• Certifications
  CE，KC

• Function
  lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR etc.; Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）

Performance

• Focal Length
  6.72 mm

• Working Distance
  110 mm

• Field of View
  86×69 mm

• Max. Read Speed
  45 codes/s

• Min. Resolution
  1D code 0.15 mm/ 2D code 0.34 mm

• Light Source Type
  White

Port

• Connector
  Industrial-grade M12 connectors are Ethernet and GPIO interfaces

• Network Port
  100M Ethernet

• GPIO Interface
  1× RS232 interface, 1x Opto-isolated input, 1× Opto-isolated output, 1 configurable input and output

• Communication Mode
  RS232, Ethernet

• Communication protocol
  SDK，TCP Client，TCP Server，FTP，RS232，Profinet、Modbus、EtherNet/IP、MC(SLMP)、FINS/UDP、FINS/TCP

• LED Indicator
  Power indicator, Network indicator, Result indicator

Power

• Power Supply
  9~26VDC, 0.5A input, suitable for industrial environment

• Power Consumption
  <4.5 W

Structure

• Product Dimensions
  52 mm × 50 mm × 28 mm (Without cable)

• Net Weight
  <130 g

• Protection
  IP65

• Casing Material
  Aluminum alloy + Front cover

Environment

• Operating Temperature
  -20℃～+50℃

• Operating Humidity
  20%～95%, Non condensing

• Storage Temperature
  -30℃～+70℃
