Basic

• Resolution
  1280 × 1024

• Max. Frame rate
  60 fps

• Shutter Mode
  Global

• Lens Mount
  M8

• Trigger Mode
  Support multiple trigger modes such as software trigger/external trigger/free run;

• Software
  EasyID

• Certifications
  CE，KC

• Function
  lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR/PDF417 etc.; Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）

• Focal Length
  4.8 mm

• Focus Control
  Manual control

• Light Source Type
  Red/white dual light

Performance

• Working Distance
  40 - 150 mm

• Field of View
  31 × 24 mm - 110 × 88 mm

• Max. Read Speed
  31 codes/s

• Min. Resolution
  1D code 0.05mm / 2D code 0.08mm

• Sight
  Red light indication

Port

• Connector
  Industrial-grade M12 connectors are Ethernet and GPIO interfaces

• Network Port
  100M Ethernet

• GPIO Interface
  1× RS232 interface, 1× Opto-isolated input, 1× Opto-isolated output, 1 configurable input and output

• Communication Mode
  RS232, Ethernet

• Communication protocol
  SDK, TCP Client, FTP, TCP Server, RS232, Profinet, Modbus, EtherNet/IP, MCUdp, MCTcp, FinsUDP, FinsTCP, MELSEC

• LED Indicator
  Power indicator, Network indicator, Result indicator

Power

• Power Supply
  Support DC 9V～26V wide range voltage input

• Power Consumption
  <2.5W

Structure

• Product Dimensions
  50mm × 50mm × 28.5mm (Without cable)

• Net Weight
  ＜130 g

• Protection
  IP65

• Casing Material
  Aluminum alloy + Front cover

Environment

• Operating Temperature
  -20℃～+50℃

• Operating Humidity
  20%～95%, Non-condensing

• Storage Temperature
  -30℃～+70℃
