● Support brightness enhancement, gamma correction, LUT and other ISP functions;
● Support PRNU correction in target bright field;
● Support various image formats of output data;
● Support DC12~24V wide-range power supply;
● Conform to CE, FCC, UL, RoHS certifications;
ไม่มีสินค้าในสต็อก
สอบถามเพิ่มเติม
N/A
Amason
มั่นใจสินค้าทุกชิ้นมีประกัน 1 ปี
จัดส่งฟรี
ผ่านทาง DHL
Basic
-
Sensor4K
-
Image SensorCMOS
-
ShutterGlobal
-
Resolution4096 × 2
-
Line Rate92 kHz
-
Bit Depth12
-
Mono/ColorColor
-
Pixel Size7 μm × 7 μm
-
Pixel4096×2
-
S/N Ratio39.4 DB
-
Dynamic Range66 dB
-
Image FormatBayerRG8,RGB8
-
BinningSupport
-
ROISupport
-
X FlipSupport
-
Gain1–32
-
White BalanceSupport
-
GammaFrom 0 to 4，support LUT
-
Exposure Time4 us–100 ms
-
Trigger ModeSoftware Trigger/Hardware Trigger/Free Run Mode
-
FPNSupport
Performance
-
User SettingSupport two sets of user-defined configurations
-
Pixel Clock34/51/64/85 MHz
Port
-
PortCameraLink
-
Lens MountM42
Power
-
Power Supply12V～24 VDC power supply
-
Power Consumption4.5 W
Structure
-
Product Dimensions62 mm × 62 mm × 33.7 mm (Not including rear case connector)
-
Net Weight200 g
Environment
-
Storage Temperature- 30℃–+80℃
-
Operating Temperature- 30℃–+50℃
